HOME Products Fenders Cell Fenders, W Fenders, DC Fenders, DD Fenders, Keyhole Fenders

Cell Fenders




HEIGHT (H) 150 mm to 1000 mm
WIDTH (W) 300 mm to 2000 mm
LENGTH (L) 500 mm to 3500 mm
DEFLECTION (d) RANGE 45% to 50%
ENERGY ABSORPTION (E) RANGE (Ton-M) 0,3 to 120
REACTION FORCE (R) RANGE (Tons) 5,5 to 410
(E/R) x d RATIO 0,34
FACE PRESSURE (Ton/m2) 47 to 111
USE OF FRONTAL FRAME reduces Hull pressure up to 25-30 Ton/m2
HEIGHT (H) 300 mm to 1000 mm
WIDTH (W) 600 mm to 2000 mm
LENGTH (L) 500 mm to 3700 mm
DEFLECTION (d) RANGE 52,5% to 55%
ENERGY ABSORPTION (E) RANGE (Ton-M) 2,3 to 99
REACTION FORCE (R) RANGE (Tons) 17,5 to 299
(E/R) x d RATIO 0,42
FACE PRESSURE (Ton/m2) 79 to 146
USE OF FRONTAL FRAME reduces Hull pressure up to 25-30 Ton/m2
HEIGHT (H) 250 mm to 1000 mm
WIDTH (W) 625 mm to 2500 mm
LENGTH (L) 500 mm to 3700 mm
DEFLECTION (d) RANGE 50% to 57,5%
ENERGY ABSORPTION (E) RANGE (Ton-M) 1,5 to 110
REACTION FORCE (R) RANGE (Tons) 15 to 322
(E/R) x d RATIO 0,39 to 0,41
FACE PRESSURE (Ton/m2) 49 to 92
USE OF FRONTAL FRAME generally not used with frontal frame
HEIGHT (H) 150 mm to 2000 mm
WIDTH (W) 75 mm to 1000 mm
LENGTH (L) 500 mm to 3500 mm
DEFLECTION (d) RANGE 45% to 50%
ENERGY ABSORPTION (E) RANGE (Ton-M) 0,15 to 44
REACTION FORCE (R) RANGE (Tons) 4,85 to 99
(E/R) x d RATIO 0,45
FACE PRESSURE (Ton/m2) 47 to 50
USE OF FRONTAL FRAME generally not used with frontal frame


W Fenders



DC Fenders



DD Fenders



Keyhole Fenders
