| SIZE (Diametre x Length) mm
|
ENERGY ABSORPTION (E) at 60% Deflection
(Ton-M)
(initial
Air pressure in Kg/cm2
|
REACTION FORCE (R) at 60% Deflection
(Ton)
|
| |
|
0,5 |
0,8 |
0,5 |
0,8 |
| 500 |
1000 |
0,62 |
0,81 |
6,44 |
8,63 |
| 660 |
1160 |
0.8 |
1.1 |
7.5 |
9.8 |
| 700 |
1500 |
1,72 |
2,44 |
13,66 |
18,37 |
| 1000 |
1500 |
3,40 |
4,58 |
18,12 |
24,36 |
| 1000 |
2000 |
4,70 |
6,52 |
25,74 |
34,61 |
| 1200 |
2000 |
6,34 |
8,96 |
29,70 |
39,89 |
| 1350 |
2500 |
10,80 |
14,56 |
42,67 |
57,35 |
| 1500 |
3000 |
15.4 |
21.5 |
58.5 |
76.6 |
| 1700 |
3000 |
19,50 |
26,96 |
63,86 |
85,87 |
| 2200 |
3500 |
32.5 |
45.7 |
89.1 |
117.2 |
| 2200 |
4500 |
51,20 |
70,85 |
127,71 |
171,54 |
| 2500 |
4000 |
67,30 |
94,57 |
137,61 |
185,75 |
| 2500 |
5500 |
96,60 |
134,38 |
201,96 |
271,01 |
| 3300 |
4500 |
119,20 |
167,08 |
188,10 |
252,74 |
| 3300 |
6500 |
185,00 |
258,57 |
300,96 |
404,99 |
| 3300 |
10600 |
310,50 |
437,74 |
525,69 |
706,44 |
| 4500 |
6500 |
284.4 |
350.2 |
420.6 |
565.2 |
| 4500 |
9000 |
481,50 |
673,24 |
574,20 |
772,42 |
| 4500 |
12000 |
656,40 |
914,34 |
797,94 |
1072,90 |
|
|
Brochure Hi-Tech Elastomers Ltd |
|
|
PDF format, dimension 1.129KB
|
|
|
|
|
|
